Type : |
Positive working thermal CTP plate |
|
Substrate : |
Electro-chemically grained and anodized lithographic-grade aluminum with hydrophilic treatment |
|
Spectral sensitivity : |
830nm |
|
Exposure energy : |
120mj/cm2 |
|
Resolution : |
1 ~ 99% @ 450lpi |
|
Run length : |
250,000 impressions unbaked and 1,000,000 impressions post-baked
* Run length depends on exposure power, processing and printing quality controls and conditions. |
|
UV ink compatibility : |
Applicable with UV inks when post-baked |
|
Sizes : |
Maximum width is 1450mm
Diagonal tolerance is no greater than 0.5mm |
|
Shelf life: |
18 months when away from excessive cold, heat and humidity |
|
Post-Baking Recommendation : |
230 ~ 2500 C, 5 ~ 8 minutes |
